Operation
BAS-SVX08D-E432
Table 13 - Continued
10026 25 1 = unit or circuit 1 automatic reset fault bit
10027 26 1 = unit or circuit 2 automatic reset fault bit
10028 27 1 = circuit 1 is limited or not ready bit
10029 28 1 = circuit 2 is limited or not ready bit
10030 29 1 = unit information alarm bit
10031 30 1 = unit default LED in ON bit
10032 31 1 = menu B 07 on Remote position bit
10033 32 1 = unit stopped by external input bit
10034 33 1 = unit stopped by serial link bit
10035 34 1 = unit stopped by operator bit
10036 35 1 = unit stopped by keypad bit
10037 36 1 = no EVP water flow while the unit is running bit
10038 37 1 = unit stopped by low ambient bit
10039 38 1 = no EVP water flow while the unit is stopped bit
10040 39 1 = EVP water flow established bit
10041 40 1 = fan speed inverter failure bit
30001 0 EVP circuit 1 leaving water temperature Temperature
30002 1 saturated EVP 1 refrigerant temperature Temperature
30003 2 saturated CDS 1 refrigerant temperature Temperature
30004 3 EVP circuit 2 leaving water temperature Temperature
30005 4 saturated EVP 2 refrigerant temperature Temperature
30006 5 saturated CDS 2 refrigerant temperature Temperature
30007 6 air temperature Temperature
30008 7 CDS leaving water temperature Temperature
30009 8 EVP entering water temperature Temperature
30010 9 CDS entering water temperature Temperature
30011 10 saturated EVP 1 refrigerant pressure Pressure
30012 11 saturated CDS 1 refrigerant pressure Pressure
30013 12 saturated EVP 2 refrigerant pressure Pressure
30014 13 saturated CDS 2 refrigerant pressure Pressure
30015 14 regulation temperature Temperature
30016 15 active EVP water temperature setpoint Temperature
30017 16 diagnostic code None
30018-30019 17-18 start counter of the comrpessor A1 None
30020-30021 19-20 start counter of the compressor A2 None
30022-30023 21-22 start counter of the compressor B1 None
30024-30025 23-24 start counter of the compressor B2 None
30026-30027 25-26 operating hours of the compressor A1 Hours
30028-30029 27-28 operating hours of the compressor A2 Hours
30030-30031 29-30 operating hours of the compressor B1 Hours
30032-30033 31-32 operating hours of the compressor B2 Hours
Bit 7 1 = unit in heating mode
Bit 6 1 = active remote water setpoint
Bit 5 1 = module I/O4 communication fault
Bit 4 1 = module I/O3 communication fault
Bit 3 1 = module I/O2 communication fault
Bit 2 1 = module I/O1 communication fault bitfield
Analog
Inputs
4
30034 33
Binary
Inputs
2
Data
Type
Offset Point Description UnitFunction
Modbus
Index
