Trane PIC - Page 57

Operation
57BAS-SVX08D-E4
Table 19
Table 20
SW2 - Trane Equipment Configuration
Trane Equipment Controller 12345678
RTAC (Chiller Profile) CH530 OFF OFF OFF OFF OFF OFF
Reserved
CVGF CH530 ON OFF OFF OFF OFF OFF
RTHD CH530 OFF ON OFF OFF OFF OFF
CGAN / CXAN / CGCL /
CCUH / CCUN / CGWH /
CGWN / RAUL / CGAM /
CXAM
CH530 ON ON OFF OFF OFF OFF
CGAN / CXAN CH532 V1.2 OFF OFF ON OFF OFF OFF
CGAN / CXAN CH532 V2.0 ON OFF ON OFF OFF OFF
RTAA / RTAB / RTXA /
RTAD / RTWB / RTRA /
RTUB
UCM CLD OFF ON ON OFF OFF OFF
RTAC (Public Extension) CH530 ON ON ON OFF OFF OFF
RTWD / RTUD CH530 OFF OFF OFF ON OFF OFF
SW1 - Trane Equipment Configuration
Trane Equipment Controller 1234567
8
RTAC (Chiller Profile) CH530 OFF OFF OFF OFF
Reserved
OFF
CVGF CH530 OFF OFF OFF OFF
OFF
RTHD CH530 OFF OFF OFF OFF
OFF
CGAN / CXAN / CGCL /
CCUH / CCUN / CGWH /
CGWN / RAUL / CGAM /
CXAM
CH530 OFF OFF OFF OFF
OFF
CGAN / CXAN CH532 V1.2 OFF OFF OFF OFF
OFF
CGAN / CXAN CH532 V2.0 OFF OFF OFF OFF
OFF
RTAA / RTAB / RTXA /
RTAD / RTWB / RTRA /
RTUB
UCM CLD OFF OFF OFF OFF
OFF
RTAC (Public Extension) CH530 OFF OFF OFF OFF
OFF
RTWD / RTUD
CH530
OFF OFF OFF OFF OFF
