Operation
BAS-SVX08D-E460
Table 21
Table 22
SW2 - Trane Equipment Configuration
Trane Equipment Controller 12345678
CGAH / CXAH / CGCL /
CCUH / CGWH / RAUL
SMM OFF OFF OFF OFF OFF OFF
Reserved
RTAA / RTAB / RTXA /
RTAD / RTWB / RTRA /
RTUB
UCM CLD OFF OFF OFF OFF OFF OFF
CVGE / CVAE / RTHC UCP2 OFF OFF OFF OFF OFF OFF
WSD / WSH / WKD /
WKH / TCD / TCH / TED /
TEH / TSD / TSH / TKD /
TKH / YCD / YCH / YSD /
YSH / YKD / YKH
Reliatel or
UCP II
OFF OFF OFF OFF OFF OFF
SW1 - Trane Equipment Configuration
Trane Equipment Controller 12345678
CGAH / CXAH / CGCL /
CCUH / CGWH / RAUL
SMM OFF OFF OFF OFF
Reserved
ON
RTAA / RTAB / RTXA /
RTAD / RTWB / RTRA /
RTUB
UCM CLD OFF ON OFF OFF ON
CVGE / CVAE / RTHC UCP2 ON ON OFF OFF ON
WSD / WSH / WKD /
WKH / TCD / TCH / TED /
TEH / TSD / TSH / TKD /
TKH / YCD / YCH / YSD /
YSH / YKD / YKH
Reliatel or
UCP II
ON OFF OFF OFF ON
