Table 4. Group 4 accessories settings
Menu Item Options [Default] Description
Filtration Type Installed
Air Cleaner,
[Media Filter]
Select the filter type installed
Humidifier Installed
[None], Yes Select whether a humidifier is installed
Humidifier — Select Aux Contact
(a)
[Aux1], Aux2 Select which set of Aux contacts is controlling the
humidifier
Humidifier Type [Powered/Bypass], Steam Select what type of humidifier is installed
Humidifier Control
[RH Control], Frost Control Select how the humidifier will be controlled [A wired
Outdoor Air Temperature sensor must be
connected to ODT input and ODT input must be set
to Outdoor Air Temperature to allow Frost Control
to be selected.]
Humidifier Fan Action
[Humidity with active Heat Call], Humidity without
active Heat Call
Select when the humidifier is allowed to operate.
Airflow During Humidifier Only Mode
35% to 100% Select the desired airflow when the humidifier is
operating without an active call for heat — requires
variable speed blower.
(b)
.
UV Light Installed [None], Yes Select whether a UV Light is installed.
Ventilation installed [None], Yes Select whether ventilation is installed.
Ventilation — Select Aux Contact Aux1, [Aux2] Select which set of Aux contacts is controlling the
ventilation system.
Ventilation Relay
[On Ventilation Closed], On Ventilation Open
(c)
Select whether ventilation is on when contact relay
is closed or open.
Minimum Ventilation Run Time
0–60 Minutes, [5 Minutes]
(c)
Select minimum runtime per hour for ventilation
system.
Ventilation Fan Action
[Ventilate with Blower], Ventilate without Blower Select whether ventilation will run with the fan or
without the fan.
Ventilate with blower – Ventilation is provided
through the roof top unit.
Ventilate without blower – Ventilation will be
provided by a dedicated ventilation system.
Outdoor Air Temperature Ventilation Override
[Disable], Enable Select whether an outdoor temperature overrride is
allowed (Outdoor air temperature sensor must be
connected and enabled, or Internet Weather
enabled to allow this setting to be selected).
Ventilation — Minimum Outdoor Air Temperature
-10°F to 50°F [0°F] Select the minimum outdoor temperature that
ventilation is allowed.
Ventilation — Maximum Outdoor Air Temperature
80°F to 110°F [0°F] Select the maximum outdoor temperature that
ventilation is allowed.
Accumulate Overridden Runtime
[No], Yes Select whether the overridden ventilation runtime
will be made up.
Accumulated Period
[4 hours – recover based on outdoor conditions]
24 hours – recover based on outdoor conditions
4 hours – recover to maintain minimum ventilation
24 hours – recover to maintain minimum ventilation
Select when to recover missed ventilation runtime
due to outdoor conditions exceeding the minimum/
maximum outdoor temperature setting (The first
two options will not meet ASHRAE 62.2 Standard
for minimum ventilation requirements).
Dehumidification Installed
[None], Yes Select whether a dehumidifier is installed.
Dehumidification — Select Aux Contact
(a)
Aux1, [Aux2] Select which set of aux contacts is controlling the
ventilation system.
Dehumidification Control Options
[Stand alone Operation], With Active Call for
Cooling Only
Select when the dehumidifier is allowed to operate.
Run System Fan with Dehumidification Request
Yes, [No] Select if the indoor fan should operate with a call
for dehumidifier operation.
