Table 6. Oil type and oil charge for RTHD chillers with AFD
Unit Configuration
(a)
B1B1B1 B1C1D1 B2B2B2 B2C2D2 C1D5E4 C1D6E5 C1E1F1 C2D3E3
Oil Type Solest 120 (OIL00315/317)
Oil Charge, gal 7.5 7.5 7.5 7.5 10 10 11 10
Oil Charge, L 28.5 28.5 28.5 28.5 38 38 42 38
Unit Configuration
(a)
C2D4E4 C2F2F3 D1D1E1 D1F1F2 D1G1G1 D1G2G2 D2D2E2 D2F2F3
Oil Type Solest 120 (OIL00315/317)
Oil Charge, gal 10 12 9.5 11 13.5 13.5 9.5 11
Oil Charge, L 38 45.5 36 42 51 51 36 42
Unit Configuration
(a)
D2G2G1 D2G3G3 D3D2E2 D3F2F3 D3G2G1 E3D2E2 E3F2F3 E3G2G1
Oil Type Solest 120 (OIL00315/317)
Oil Charge, gal 13.5 13.5 9.5 11 13.5 9.5 11 13.5
Oil Charge, L 5151364251364251
(a) Unit configuration digits 1, 2 = compressor code (also shown in unit model number digits 6, 7); digits 3, 4 = evaporator code (unit model number digits 14, 15); digits 5, 6 =
condenser code (unit model number digits 21, 22).
