28
S9XB-SVX001-1D-EN
Table 7. 1st Stage Heating Table — Upflow
CFM VS. 1ST STAGE TEMPERATURE RISE
MODEL
500 600 700 800 900 1000 1100 1200 1300 1400 1500 1600 1700 1800 1900 2000 2100
S9X2B040U3PSBB 47 39 33 29 26
S9X2B060U4PSBB 50 44 39 35 32 29 27 25
S9X2B080U4PSBB 58 52 47 42 39 36 33 31
S9X2C080U5PSBB 58 52 47 42 39 36 33 31
S9X2C100U5PSBB 53 49 45 42 39 36 34 32 31 29 28
S9X2D120U5PSBB 58 54 50 47 44 41 39 37 35 33
Table 8. 2nd Stage Heating Table — Downflow
CFM VS. 2ND STAGE TEMPERATURE RISE
MODEL
CFM (CUBIC FEET PER MINUTE)
600 700 800 900 1000 1100 1200 1300 1400 1500 1600 1700 1800 1900 2000 2100 2200 2300
S9X2B040D3PSBB 60 51 45 40 36 33
S9X2B060D3PSBB 64 61 57 54 49 45 41 38 36
S9X2B080D4PSBB 72 65 60 55 51 48
S9X2C100D5PSBB 69 64 60 56 53 50 47 45 43 41
S9X2D120D5PSBB 72 67 63 60 57 54 51 49 47
Table 9. 1st Stage Heating Table — Downflow
CFM VS. 1ST STAGE TEMPERATURE RISE
MODEL
500 600 700 800 900 1000 1100 1200 1300 1400 1500 1600 1700 1800 1900 2000 2100
S9X2B040D3PSBB 47 39 33 29 26
S9X2B060D3PSBB 49 46 44 39 35 32 29 27 25
S9X2B080D4PSBB 58 52 47 42 39 36 33 31
S9X2C100D5PSBB 53 49 45 42 39 36 34 32 31 29 28
S9X2D120D5PSBB 58 54 50 47 44 41 39 37 35 33
