Trane S9X1 - Airflow Tables

24
S9XB-SVX001-1D-EN
Airflow Tables
UUppffllooww
Furnace Airflow (CFM) Vs. External Static Pressure (in. W.C.)
Model
Tap
0.1 0.3 0.5 0.7 0.9
S9X1B040U3PSBB
S9B1B040U3PSAB
S9X2B040U3PSBB
1
SCFM / Watts 510 / 34 314 / 43 118 / 52
- -
2
SCFM / Watts 532 / 36 341 / 45 150 / 54
- -
3
SCFM / Watts 877 / 91 748 / 104 620 / 118 491 / 131 362 / 144
4
SCFM / Watts 933 / 106 813 / 120 693 / 133 573 / 147 452 / 161
5
SCFM / Watts 1056 / 140 950 / 156 843 / 172 737 / 188 631 / 204
6
SCFM / Watts 1111 / 157 1009 / 174 908 / 190 806 / 207 705 / 223
7
SCFM / Watts 1174 / 182 1078 / 199 983 / 216 887 / 233 791 / 251
8
SCFM / Watts 1376 / 285 1297 / 305 1218 / 325 1140 / 344 1061 / 364
9
SCFM / Watts 1512 / 382 1445 / 403 1378 / 424 1312 / 445 1245 / 466
Furnace Airflow (CFM) Vs. External Static Pressure (in. W.C.)
Model
Tap
0.1 0.3 0.5 0.7 0.9
S9X1B060U4PSBB
S9B1B060U4PSAB
S9X2B060U4PSBB
1
SCFM / Watts 840 / 91 702 / 101 565 / 111 427 / 121 290 / 130
2
SCFM / Watts 1001 / 137 893 / 149 786 / 162 678 / 174 571 / 186
3
SCFM / Watts 1140 / 193 1051 / 207 963 / 221 875 / 235 786 / 249
4
SCFM / Watts 1208 / 223 1128 / 238 1048 / 253 969 / 268 889 / 283
5
SCFM / Watts 1299 / 270 1224 / 284 1148 / 298 1073 / 312 998 / 327
6
SCFM / Watts 1413 / 343 1348 / 359 1283 / 375 1217 / 391 1152 / 406
7
SCFM / Watts 1444 / 354 1380 / 370 1315 / 386 1251 / 403 1186 / 419
8
SCFM / Watts 1727 / 612 1674 / 631 1622 / 650 1570 / 668 1518 / 687
9
SCFM / Watts 1790 / 694 1741 / 712 1691 / 729 1642 / 747 1593 / 765
Furnace Airflow (CFM) Vs. External Static Pressure (in. W.C.)
Model
Tap
0.1 0.3 0.5 0.7 0.9
S9X1B080U4PSBB
S9B1B080U4PSAB
S9X2B080U4PSBB
1
SCFM / Watts 911 / 94 766 / 104 622 / 115 477 / 125 332 / 136
2
SCFM / Watts 1075 / 139 963 / 153 851 / 168 740 / 182 628 / 197
3
SCFM / Watts 1215 / 185 1121 / 202 1028 / 219 934 / 236 840 / 253
4
SCFM / Watts 1250 / 203 1164 / 221 1077 / 239 990 / 257 903 / 274
5
SCFM / Watts 1349 / 251 1272 / 271 1194 / 291 1116 / 310 1039 / 330
6
SCFM / Watts 1453 / 313 1387 / 335 1321 / 356 1254 / 378 1188 / 400
7
SCFM / Watts 1505 / 340 1438 / 362 1372 / 384 1305 / 406 1239 / 427
8
SCFM / Watts 1657 / 453 1597 / 477 1538 / 500 1479 / 524 1419 / 547
9
SCFM / Watts 1878 / 669 1815 / 686 1752 / 702 1690 / 718 1627 / 735
