Trane S9X1 - Product Specifications

S9XB-SVX001-1D-EN
11
Product Specifications
MODEL
S9X1B040U3PSBB
(a)
S9B1B040U3PSAB
S9X1B060U4PSBB
(a)
S9B1B060U4PSAB
S9X1B080U4PSBB
(a)
S9B1B080U4PSAB
S9X1C080U5PSBB
(a)
S9B1C080U5PSAB
TYPE
Upflow / Horizontal Upflow / Horizontal Upflow / Horizontal Upflow / Horizontal
RATINGS
(b)
Input BTUH 40,000 60,000 80,000 80,000
Capacity BTUH (ICS)
(c) (d)
39,000 58,300 77,200 77,800
Temp. Rise (Min.-Max.)
30 - 60 30 - 60 45 - 75 40 - 70
AFUE (%) S9X1 / S9B1
(d)
96.0 / 92.1 96.0 / 92.1 96.0 / 92.1 96.0 / 92.1
Return Air Temp. (Min. - Max.)
45°F - 80°F 45°F - 80°F 45°F - 80°F 45°F - 80°F
BLOWER DRIVE DIRECT DIRECT DIRECT DIRECT
Diameter — Width (In.)
11 X 8 11 X 8 11 X 8 11 X 10
No. Used 1 1 1 1
Speeds (No.)
(e)
9 9 9 9
CFM vs. in. w.g.
See Fan Performance Table See Fan Performance Table See Fan Performance Table See Fan Performance Table
Motor HP
1/2 3/4 3/4
1
RPM 1075 1075 1075 1075
Volts/Ph/Hz 120 / 1 / 60 120 / 1 / 60 120 / 1 / 60 120 / 1 / 60
FLA 6.4 8.4 8.4 10.6
COMBUSTION FAN — Type Centrifugal Centrifugal Centrifugal Centrifugal
Drive — No. Speeds
Direct - 1 Direct - 1 Direct - 1 Direct - 1
Motor HP — RPM 3300 3300 3300 3300
Volts/Ph/Hz 120 / 1 / 60 120 / 1 / 60 120 / 1 / 60 120 / 1 / 60
FLA 2.14 2.14 2.14 0.66
FILTER — Furnished? No No No No
Type recommended High Velocity High Velocity High Velocity High Velocity
Hi Vel. (No.-Size-Thk.)
1 - 16 X 25 - 1 in. 1 - 16 X 25 - 1 in. 1 - 16 X 25 - 1 in. 1 - 20 X 25 - 1 in.
VENT PIPE DIAMETER — Min
(in.)
(f) (g)
2 Round 2 Round 2 Round 2 Round
HEAT EXCHANGER
Type — Fired
409 Stainless Steel 409 Stainless Steel 409 Stainless Steel 409 Stainless Steel
— Unfired 29–4C Stainless Steel 29–4C Stainless Steel 29–4C Stainless Steel 29–4C Stainless Steel
Gauge (Fired)
20 20 20 20
ORIFICES — Main
Nat. Gas Qty. — Drill Size
2 - 45 3 - 45 4 - 45 4 - 45
LP Gas Qty. — Drill Size
2 - 56 3 - 56 4 - 56 4 - 56
GAS VALVE
Redundant - One Stage Redundant - One Stage Redundant - One Stage Redundant - One Stage
PILOT SAFETY DEVICE
Type 120 V SiNi Igniter 120 V SiNi Igniter 120 V SiNi Igniter 120 V SiNi Igniter
BURNERS — Type Multiport Inshot Multiport Inshot Multiport Inshot Multiport Inshot
Number 2 3 4 4
POWER CONN. — V/Ph/Hz
(h)
120 / 1 / 60 120 / 1 / 60 120 / 1 / 60 120 / 1 / 60
Ampacity (In Amps)
10.3 12.8 12.8 14.1
Max. Overcurrent Protection
(Amps)
15 15 15 15
PIPE CONN. SIZE (in.)
1/2 1/2 1/2 1/2
