Trane S9X1 - Page 12

12
S9XB-SVX001-1D-EN
MODEL
S9X1C100U5PSBB
(a)
S9B1C100U5PSAB
S9X1D120U5PSBB
(a)
S9B1D120U5PSAB
S9X1B040D3PSBB
(a)
S9B1B040D3PSAB
S9X1B060D3PSBB
(a)
S9B1B060D3PSAB
TYPE
Upflow / Horizontal Upflow / Horizontal
Downflow Downflow
RATINGS
(b)
Input BTUH 100,000 120,000 40,000 60,000
Capacity BTUH (ICS)
(c) (d)
97,400 113,400 38,900 57,600
Temp. Rise (Min.-Max.)
40 - 70 40-70 30 - 60 35 - 65
AFUE (%) S9X1 / S9B1
(d)
95.0 / 92.1 95.0 / 92.1 96.0 / 92.1 96.0 / 92.1
Return Air Temp. (Min. - Max.)
45°F - 80°F 45°F - 80°F 45°F - 80°F 45°F - 80°F
BLOWER DRIVE DIRECT DIRECT DIRECT DIRECT
Diameter — Width (In.)
11 X 10 11 X 10 11 X 8 11 X 8
No. Used 1 1 1 1
Speeds (No.)
(e)
9 9 9 9
CFM vs. in. w.g.
See Fan Performance Table See Fan Performance Table See Fan Performance Table See Fan Performance Table
Motor HP 1 1
1/2 1/2
RPM 1075 1075 1075 1075
Volts/Ph/Hz 120 / 1 / 60 120 / 1 / 60 120 / 1 / 60 120 / 1 / 60
FLA 10.6 10.6 6.4 6.4
COMBUSTION FAN — Type Centrifugal Centrifugal Centrifugal Centrifugal
Drive — No. Speeds
Direct - 1 Direct - 1 Direct - 1 Direct - 1
Motor HP — RPM 3300 3300 3300 3300
Volts/Ph/Hz 120 / 1 / 60 120 / 1 / 60 120 / 1 / 60 120 / 1 / 60
FLA 0.66 0.66 2.14 2.14
FILTER — Furnished? No No No No
Type recommended High Velocity High Velocity High Velocity High Velocity
Hi Vel. (No.-Size-Thk.)
1 - 20 X 25 - 1 in. 1 - 24 X 25 - 1 in. 1 - 16 X 25 - 1 in. 1 - 16 X 25 - 1 in.
VENT PIPE DIAMETER — Min
(in.)
(f) (g)
2 Round 3 Round 2 Round 2 Round
HEAT EXCHANGER
Type — Fired
409 Stainless Steel 409 Stainless Steel 409 Stainless Steel 409 Stainless Steel
— Unfired 29–4C Stainless Steel 29–4C Stainless Steel 29–4C Stainless Steel 29–4C Stainless Steel
Gauge (Fired)
20 20 20 20
ORIFICES — Main
Nat. Gas Qty. — Drill Size
5 - 45 6 - 45 2 - 45 3 - 45
LP Gas Qty. — Drill Size
5 - 56 6 - 56 2- 56 3 - 56
GAS VALVE
Redundant - One Stage Redundant - One Stage Redundant - One Stage Redundant - One Stage
PILOT SAFETY DEVICE
Type 120 V SiNi Igniter 120 V SiNi Igniter 120 V SiNi Igniter 120 V SiNi Igniter
BURNERS — Type Multiport Inshot Multiport Inshot Multiport Inshot Multiport Inshot
Number 5 6 2 3
POWER CONN. — V/Ph/Hz
(h)
120 / 1 / 60 120 / 1 / 60 120 / 1 / 60 120 / 1 / 60
Ampacity (In Amps)
14.1 14.1 10.3 10.3
Max. Overcurrent Protection
(Amps)
15 15 15 15
PIPE CONN. SIZE (in.)
1/2 1/2 1/2 1/2
