S9XB-SVX001-1D-EN
27
CFM Versus Temperature Rise
S9X1 and S9B1 furnaces have one stage heating.
S9X2 Furnaces have two stage heating. First Stage is Low heating and Second Stage is High heating.
Table 4. Heating Table — Upflow
CFM VS. TEMPERATURE RISE
MODEL
CFM (CUBIC FEET PER MINUTE)
700 800 900 1000 1100 1200 1300 1400 1500 1600 1700 1800 1900 2000 2100 2200 2300
S9X1B040U3PSBB
S9B1B040U3PSAB
55 48 44 39 36 33 30
S9X1B060U4PSBB
S9B1B060U4PSAB
63 58 52 49 46 43 41 40
S9X1B080U4PSBB
S9B1B080U4PSAB
71 68 64 61 57 54 51 48 45
S9X1C080U5PSBB
S9B1C080U5PSAB
68 65 59 56 54 49 46 44
S9X1C100U5PSBB
S9B1C100U5PSAB
68 65 61 57 55 53 49 46
S9X1D120U5PSBB
S9B1D120U5PSAB
67 65 60 55 54 51 48 44 41
Table 5. Heating Table — Downflow
CFM VS. TEMPERATURE RISE
MODEL
CFM (CUBIC FEET PER MINUTE)
500 600 700 800 900 1000 1100 1200 1300 1400 1500 1600 1700 1800 1900 2000 2100 2200 2300
S9X1B040D3PSBB
S9B1B040D3PSAB
57 53 46 45 37 34 31
S9X1B060D3PSBB
S9B1B060D3PSAB
63 58 52 48 44 41
S9X1B080D4PSBB
S9B1B080D4PSAB
72 69 65 62 57 53 49 48
S9X1C100D5PSBB
S9B1C100D5PSAB
68 65 62 58 55 53 50 48 44
S9X1D120D5PSBB
S9B1D120D5PSAB
72 69 66 64 58 56 53 52 49 44
Table 6. 2nd Stage Heating Table — Upflow
CFM VS. 2ND STAGE TEMPERATURE RISE
MODEL
CFM (CUBIC FEET PER MINUTE)
600 700 800 900 1000 1100 1200 1300 1400 1500 1600 1700 1800 1900 2000 2100 2200 2300
S9X2B040U3PSBB 60 51 45 40 36 33
S9X2B060U4PSBB 60 54 49 45 41 38 36 34 32
S9X2B080U4PSBB 72 65 60 55 51 48
S9X2C080U5PSBB 65 60 55 51 48 45 42
S9X2C100U5PSBB 69 64 60 56 53 50 47 45 43
S9X2D120U5PSBB 67 63 60 57 54 51 49 47
To Next Page
