Trane S9X1 - Page 26

26
S9XB-SVX001-1D-EN
Furnace Airflow (CFM) Vs. External Static Pressure (in. W.C.)
Model
Tap
0.1 0.3 0.5 0.7 0.9
S9X1B060D3PSBB
S9B1B060D3PSAB
S9X2B060D3PSBB
1
SCFM / Watts 624 / 47 451 / 57 277 / 68 104 / 79
-
2
SCFM / Watts 866 / 89 734 / 102 602 / 116 470 / 129 338 / 142
3
SCFM / Watts 949 / 113 833 / 128 718 / 142 602 / 156 486 / 171
4
SCFM / Watts 1122 / 165 1025 / 182 928 / 200 831 / 217 733 / 235
5
SCFM / Watts 1178 / 191 1087 / 209 996 / 227 905 / 246 814 / 264
6
SCFM / Watts 1260 / 233 1180 / 252 1100 / 271 1021 / 290 941 / 309
7
SCFM / Watts 1370 / 296 1299 / 316 1228 / 336 1158 / 355 1087 / 375
8
SCFM / Watts 1480 / 365 1416 / 387 1352 / 408 1287 / 429 1223 / 450
9
SCFM / Watts 1504 / 384 1440 / 406 1376 / 427 1312 / 449 1249 / 470
Furnace Airflow (CFM) Vs. External Static Pressure (in. W.C.)
Model
Tap
0.1 0.3 0.5 0.7 0.9
S9X1B080D4PSBB
S9B1B080D4PSAB
S9X2B080D4PSBB
1
SCFM / Watts 499 / 36 306 / 43 113 / 49
- -
2
SCFM / Watts 1017 / 143 922 / 158 828 / 173 734 / 188 640 / 203
3
SCFM / Watts 1119 / 176 1029 / 192 940 / 207 850 / 223 761 / 239
4
SCFM / Watts 1205 / 215 1125 / 233 1044 / 250 964 / 268 883 / 285
5
SCFM / Watts 1237 / 231 1160 / 250 1083 / 268 1006 / 286 928 / 305
6
SCFM / Watts 1378 / 315 1309 / 334 1240 / 354 1172 / 373 1103 / 393
7
SCFM / Watts 1453 / 360 1389 / 380 1324 / 399 1260 / 419 1195 / 439
8
SCFM / Watts 1618 / 496 1562 / 518 1505 / 540 1449 / 561 1392 / 583
9
SCFM / Watts 1794 / 682 1742 / 704 1691 / 726 1639 / 748 1587 / 770
Furnace Airflow (CFM) Vs. External Static Pressure (in. W.C.)
Model
Tap
0.1 0.3 0.5 0.7 0.9
S9X1C100D5PSBB
S9B1C100D5PSAB
S9X2C100D5PSBB
1
SCFM / Watts 1002 / 103 823 / 117 644 / 130 465 / 144 285 / 157
2
SCFM / Watts 1385 / 223 1276 / 243 1167 / 264 1057 / 284 948 / 304
3
SCFM / Watts 1527 / 286 1430 / 310 1333 / 333 1236 / 357 1139 / 380
4
SCFM / Watts 1610 / 328 1516 / 352 1421 / 377 1326 / 401 1231 / 425
5
SCFM / Watts 1761 / 433 1677 / 459 1593 / 486 1509 / 512 1425 / 538
6
SCFM / Watts 1861 / 492 1783 / 520 1706 / 549 1628 / 577 1551 / 605
7
SCFM / Watts 1984 / 548 1902 / 577 1820 / 606 1738 / 635 1656 / 663
8
SCFM / Watts 2173 / 728 2097 / 760 2020 / 792 1944 / 824 1867 / 856
9
SCFM / Watts 2342 / 945 2269 / 973 2196 / 1002 2123 / 1031 2050 / 1060
Furnace Airflow (CFM) Vs. External Static Pressure (in. W.C.)
Model
Tap
0.1 0.3 0.5 0.7 0.9
S9X1D120D5PSBB
S9B1D120D5PSAB
S9X2D120D5PSBB
1
SCFM / Watts 680 / 47 419 / 56 159 / 66
- -
2
SCFM / Watts 1481 / 236 1372 / 259 1264 / 282 1155 / 304 1046 / 327
3
SCFM / Watts 1566 / 268 1461 / 292 1357 / 316 1253 / 340 1149 / 363
4
SCFM / Watts 1803 / 393 1711 / 420 1619 / 446 1527 / 472 1435 / 498
5
SCFM / Watts 1891 / 445 1801 / 472 1711 / 500 1621 / 527 1532 / 555
6
SCFM / Watts 2132 / 568 2025 / 601 1919 / 633 1812 / 666 1705 / 698
7
SCFM / Watts 2154 / 644 2068 / 675 1982 / 705 1896 / 736 1810 / 766
8
SCFM / Watts 2344 / 837 2267 / 870 2190 / 902 2113 / 934 2035 / 967
9
SCFM / Watts 2414 / 896 2333 / 928 2251 / 961 2170 / 993 2088 / 1026
AAiirrffllooww TTaabblleess
