Trane S9X1 - Page 25

S9XB-SVX001-1D-EN
25
Furnace Airflow (CFM) Vs. External Static Pressure (in. W.C.)
Model
Tap
0.1 0.3 0.5 0.7 0.9
S9X1C080U5PSBB
S9B1C080U5PSAB
S9X2C080U5PSBB
1
SCFM / Watts 643 / 45 384 / 53 125 / 62
- -
2
SCFM / Watts 1125 / 126 982 / 142 838 / 158 694 / 174 551 / 190
3
SCFM / Watts 1192 / 140 1038 / 157 884 / 174 730 / 191 576 / 208
4
SCFM / Watts 1509 / 245 1377 / 268 1246 / 291 1115 / 314 983 / 337
5
SCFM / Watts 1548 / 257 1428 / 281 1308 / 304 1187 / 328 1067 / 352
6
SCFM / Watts 1602 / 320 1467 / 345 1331 / 371 1196 / 396 1061 / 421
7
SCFM / Watts 1640 / 352 1512 / 379 1383 / 406 1255 / 433 1127 / 459
8
SCFM / Watts 1831 / 521 1778 / 550 1726 / 579 1673 / 608 1621 / 637
9
SCFM / Watts 2351 / 886 2278 / 918 2204 / 950 2131 / 982 2058 / 1014
Furnace Airflow (CFM) Vs. External Static Pressure (in. W.C.)
Model
Tap
0.1 0.3 0.5 0.7 0.9
S9X1C100U5PSBB
S9B1C100U5PSAB
S9X2C100U5PSBB
1
SCFM / Watts 1013 / 104 847 / 116 680 / 129 514 / 142 348 / 155
2
SCFM / Watts 1261 / 168 1126 / 185 990 / 202 854 / 219 718 / 236
3
SCFM / Watts 1519 / 267 1407 / 290 1296 / 313 1184 / 336 1072 / 358
4
SCFM / Watts 1554 / 283 1446 / 307 1337 / 330 1229 / 353 1120 / 377
5
SCFM / Watts 1749 / 385 1651 / 411 1554 / 436 1457 / 462 1359 / 488
6
SCFM / Watts 1868 / 464 1778 / 491 1688 / 519 1599 / 546 1509 / 574
7
SCFM / Watts 2018 / 573 1936 / 602 1853 / 631 1770 / 660 1688 / 689
8
SCFM / Watts 2191 / 718 2112 / 750 2033 / 782 1954 / 815 1875 / 847
9
SCFM / Watts 2395 / 966 2303 / 981 2212 / 996 2120 / 1012 2028 / 1027
Furnace Airflow (CFM) Vs. External Static Pressure (in. W.C.)
Model
Tap
0.1 0.3 0.5 0.7 0.9
S9X1D120U5PSBB
S9B1D120U5PSAB
S9X2D120U5PSBB
1
SCFM / Watts 707 / 46 443 / 55 179 / 64
- -
2
SCFM / Watts 1344 / 163 1218 / 183 1092 / 202 966 / 222 840 / 241
3
SCFM / Watts 1532 / 225 1419 / 247 1307 / 268 1195 / 290 1083 / 312
4
SCFM / Watts 1584 / 247 1477 / 270 1370 / 292 1263 / 315 1156 / 338
5
SCFM / Watts 1915 / 401 1818 / 428 1722 / 454 1625 / 480 1529 / 506
6
SCFM / Watts 2104 / 525 2016 / 553 1927 / 582 1839 / 610 1750 / 639
7
SCFM / Watts 2132 / 546 2045 / 575 1958 / 604 1870 / 633 1783 / 662
8
SCFM / Watts 2410 / 833 2328 / 868 2247 / 903 2165 / 937 2084 / 972
9
SCFM / Watts 2472 / 909 2401 / 944 2329 / 979 2257 / 1013 2186 / 1048
DDoowwnnffllooww
Furnace Airflow (CFM) Vs. External Static Pressure (in. W.C.)
Model
Tap
0.1 0.3 0.5 0.7 0.9
S9X1B040D3PSBB
S9B1B040D3PSAB
S9X2B040D3PSBB
1
SCFM / Watts 378 / 28 153 / 32
- - -
2
SCFM / Watts 514 / 35 330 / 45 145 / 55 - / 64 - / 74
3
SCFM / Watts 765 / 69 618 / 81 471 / 93 324 / 105 178 / 116
4
SCFM / Watts 827 / 81 691 / 94 554 / 106 418 / 119 281 / 132
5
SCFM / Watts 988 / 124 879 / 140 770 / 156 661 / 171 553 / 187
6
SCFM / Watts 1085 / 156 986 / 173 887 / 190 787 / 207 688 / 224
7
SCFM / Watts 1125 / 170 1030 / 188 934 / 205 839 / 222 743 / 239
8
SCFM / Watts 1129 / 170 1035 / 187 941 / 204 847 / 221 753 / 239
9
SCFM / Watts 1492 / 369 1419 / 390 1346 / 411 1273 / 431 1200 / 452
AAiirrffllooww TTaabblleess
