Trane S9X1 - Page 13

S9XB-SVX001-1D-EN
13
MODEL
S9X1B080D4PSBB
(a)
S9B1B080D4PSAB
S9X1C100D5PSBB
(a)
S9B1C100D5PSAB
S9X1D120D5PSBB
(a)
S9B1D120D5PSAB
TYPE Downflow Downflow Downflow
RATINGS
(b)
Input BTUH 80,000 100,000 120,000
Capacity BTUH (ICS)
(c) (d)
76,900 96,800 115,500
Temp. Rise (Min.-Max.)
45 - 75 40 - 70 45 - 75
AFUE (%) S9X1 / S9B1
(d)
95.0 / 92.1 96.0 / 92.1 95.0 / 92.1
Return Air Temp. (Min. - Max.)
45°F - 80°F 45°F - 80°F 45°F - 80°F
BLOWER DRIVE DIRECT DIRECT DIRECT
Diameter — Width (In.)
11 X 8 11 X 10 11 X 10
No. Used 1 1 1
Speeds (No.)
(e)
9 9 9
CFM vs. in. w.g.
See Fan Performance Table See Fan Performance Table See Fan Performance Table
Motor HP
3/4
1 1
RPM 1075 1075 1075
Volts/Ph/Hz 120 / 1 / 60 120 / 1 / 60 120 / 1 / 60
FLA 9.3 10.6 10.6
COMBUSTION FAN — Type Centrifugal Centrifugal Centrifugal
Drive — No. Speeds
Direct - 1 Direct - 1 Direct - 1
Motor HP — RPM 3300 3300 3300
Volts/Ph/Hz 120 / 1 / 60 120 / 1 / 60 120 / 1 / 60
FLA 2.14 0.66 0.66
FILTER — Furnished? No No No
Type recommended High Velocity High Velocity High Velocity
Hi Vel. (No.-Size-Thk.)
1 - 16 X 25 - 1 in. 1 - 20 X 25 - 1 in. 1 - 24 X 25 - 1 in.
VENT PIPE DIAMETER — Min
(in.)
(f) (g)
2 Round 2 Round 3 Round
HEAT EXCHANGER
Type — Fired
409 Stainless Steel 409 Stainless Steel 409 Stainless Steel
— Unfired 29–4C Stainless Steel 29–4C Stainless Steel 29–4C Stainless Steel
Gauge (Fired)
20 20 20
ORIFICES — Main
Nat. Gas Qty. — Drill Size
4 - 45 5 - 45 6 - 45
LP Gas Qty. — Drill Size
4 - 56 5 - 56 6 - 56
GAS VALVE
Redundant - One Stage Redundant - One Stage Redundant - One Stage
PILOT SAFETY DEVICE
Type 120 V SiNi Igniter 120 V SiNi Igniter 120 V SiNi Igniter
BURNERS — Type Multiport Inshot Multiport Inshot Multiport Inshot
Number 4 5 6
POWER CONN. — V/Ph/Hz
(h)
120 / 1 / 60 120 / 1 / 60 120 / 1 / 60
Ampacity (In Amps)
13.9 14.1 14.1
Max. Overcurrent Protection
(Amps)
15 15 15
PIPE CONN. SIZE (in.)
1/2 1/2 1/2
PPrroodduucctt SSppeecciiffiiccaattiioonnss
