4.2 Set-up Wizard
The built-in wizard menu guides the installer through the
set-up of the frequency converter in a clear and structured
manner for open-loop applications, closed-loop
applications, and quick motor settings.
Illustration 4.2 Frequency Converter Wiring
The wizard is shown after power-up until any parameter
has been changed. The wizard can always be accessed
again through the quick menu. Press [OK] to start the
wizard. Press [Back] to return to the status view.
Illustration 4.3 Start-up/Quit Wizard
