Trane TR170 - Parameter List

Parameter Range Default Usage
Parameter 4-12 Motor Speed
Low Limit [Hz]
0.0–400.0 Hz 0.0 Hz Enter the minimum limit for low speed.
Parameter 4-14 Motor Speed
High Limit [Hz]
0.0–400.0 Hz 100.0 Hz Enter the maximum limit for high speed.
Parameter 4-19 Max Output
Frequency
0.0–400.0 Hz 100.0 Hz Enter the maximum output frequency value. If
parameter 4-19 Max Output Frequency is set lower than
parameter 4-14 Motor Speed High Limit [Hz],
parameter 4-14 Motor Speed High Limit [Hz] is set equal to
parameter 4-19 Max Output Frequency automatically.
Parameter 30-22 Locked Rotor
Protection
[0] O
[1] On
[0] O
–
Parameter 30-23 Locked Rotor
Detection Time [s]
0.05–1.00 s 0.10 s
–
Table 4.6 Motor Set-up Wizard Settings
Changes made
The changes made function lists all parameters changed
from default settings.
•
The list shows only parameters that have been
changed in the current edit set-up.
•
Parameters that have been reset to default values
are not listed.
•
The message Empty indicates that no parameters
have been changed.
Changing parameter settings
1. To enter the Quick Menu, press the [Menu] key
until the indicator in the display is placed above
Quick Menu.
2.
Press [
▲
] [
▼
] to select the wizard, closed-loop set-
up, motor set-up, or changes made.
3. Press [OK].
4.
Press [
▲
] [
▼
] to browse through the parameters in
the Quick Menu.
5. Press [OK] to select a parameter.
6.
Press [
▲
] [
▼
] to change the value of a parameter
setting.
7. Press [OK] to accept the change.
8. Press either [Back] twice to enter Status, or press
[Menu] once to enter the Main Menu.
The main menu accesses all parameters
1. Press the [Menu] key until the indicator in the
display is placed above Main Menu.
2.
Press [
▲
] [
▼
] to browse through the parameter
groups.
3. Press [OK] to select a parameter group.
4.
Press [
▲
] [
▼
] to browse through the parameters in
the specic group.
5. Press [OK] to select the parameter.
6.
Press [
▲
] [
▼
] to set/change the parameter value.
7. Press [OK] to accept the change.
4.3 Parameter List
