Trane TR170 - 3 X380-480 V AC

6.1.2 3x380–480 V AC
Frequency converter TR150 TR170
PK37 PK75 P1K5 P2K2 P3K0 P4K0 P5K5 P7K5 P11K P15K P1K5
Typical shaft output [kW] 0.37 0.75 1.5 2.2 3.0 4.0 5.5 7.5 11.0 15.0 1.5
Typical shaft output [hp] 0.5 1.0 2.0 3.0 4.0 5.0 7.5 10.0 15.0 20.0 2.0
Protection rating IP20 H1 H1 H1 H2 H2 H2 H3 H3 H4 H4 H2
Maximum cable size in
terminals (mains, motor)
[mm
2
(AWG)]
4 (10) 4 (10) 4 (10) 4 (10) 4 (10) 4 (10) 4 (10) 4 (10) 16 (6) 16 (6) 4 (10)
Output current - 40
° C (104 ° F) ambient temperature
Continuous (3x380–440 V)[A] 1.2 2.2 3.7 5.3 7.2 9.0 12.0 15.5 23.0 31.0 3.7
Intermittent (3x380–440 V)
[A]
1.3 2.4 4.1 5.8 7.9 9.9 13.2 17.1 25.3 34.0 4.1
Continuous (3x441–480 V)
[A]
1.1 2.1 3.4 4.8 6.3 8.2 11.0 14.0 21.0 27.0 3.4
Intermittent (3x441–480 V)
[A]
1.2 2.3 3.7 5.3 6.9 9.0 12.1 15.4 23.1 29.7 3.7
Maximum input current
Continuous (3x380–440 V)
[A]
1.2 2.1 3.5 4.7 6.3 8.3 11.2 15.1 22.1 29.9 3.5
Intermittent (3x380–440 V)
[A]
1.3 2.3 3.9 5.2 6.9 9.1 12.3 16.6 24.3 32.9 3.9
Continuous (3x441–480 V)
[A]
1.0 1.8 2.9 3.9 5.3 6.8 9.4 12.6 18.4 24.7 2.9
Intermittent (3x441–480 V)
[A]
1.1 2.0 3.2 4.3 5.8 7.5 10.3 13.9 20.2 27.2 3.2
Maximum mains fuses See chapter 3.2.3 Fuses and Circuit Breakers
.
Estimated power loss [W],
best case/typical
1)
13/15 16/21 46/57 46/58 66/83 95/118 104/131 159/198 248/274 353/379 46/57
Weight enclosure protection
rating IP20 [kg (lb)]
2.0 (4.4) 2.0 (4.4) 2.1 (4.6) 3.3 (7.3) 3.3 (7.3) 3.4 (7.5) 4.3 (9.5) 4.5 (9.9)
7.9
(17.4)
7.9
(17.4)
3.3/
(7.3)
Eciency [%],
best case/typical
2)
97.8/97.3
98.0/97.
6
97.7/97.
2
98.3/97.
9
98.2/97.8
98.0/97.
6
98.4/98.
0
98.2/97.
8
98.1/
97.9
98.0/
97.8
97.7/97.
2
Output current - 50
° C (122 ° F) ambient temperature 70 ° C
(158
° F)
Continuous (3x380–440 V)
[A]
1.04 1.93 3.7 4.85 6.3 8.4 10.9 14.0 20.9 28.0 3.7
Intermittent (3x380–440 V)
[A]
1.1 2.1 4.07 5.4 6.9 9.2 12.0 15.4 23.0 30.8 4.07
Continuous (3x441–480 V)
[A]
1.0 1.8 3.4 4.4 5.5 7.5 10.0 12.6 19.1 24.0 3.4
Intermittent (3x441–480 V)
[A]
1.1 2.0 3.7 4.8 6.1 8.3 11.0 13.9 21.0 26.4 3.7
Table 6.3 3x380–480 V AC, 0.37–15 kW (0.5–20 hp), Enclosure Sizes H1–H4
1) Applies for dimensioning of frequency converter cooling. If the switching frequency is higher than the default setting, the power losses may
increase. Keypad and typical control card power consumptions are included.
2) Typical: under rated condition.
Best case: the optimal condition is adopt, such as the higher input voltage and lower switching frequency.
