Hardwired setpoint adjustment
Table 67 Hardwired setpoint adjustment
Hardwired thermistor values
Table 68 Hardwired 10 kΩ thermistor values
Resistance (Ω )Setpoint (°F)
889.4 50
733.6 58
577.9 66
500 70
422.1 74
344.2 78
266.4 82
188.5 86
110 . 6 9 0
Resistance (k
Ω) Temperature (°F) Resistance (kΩ) Temperature (°F)
87.5 0 10.0 77
74.6 5 9.3 80
63.8 10 8.2 85
54.6 15 7.3 90
46.9 20 6.5 95
40.4 25 5.8 100
34.8 30 5.2 105
30.2 35 4.7 110
26.2 40 4.2 115
22.8 45 3.8 120
20.0 50 3.4 125
17.5 55 3.1 130
15.3 60 2.8 135
13.5 65 2.5 140
11.9 70 2.3 145
10.5 75 2.1 150
