Trane Tracer ZN.520

CNT-SVX04A-EN
11
Circuit board
Figure 1 Tracer ZN.520 zone controller circuit board
Communications
connections
Zone sensor connections
Communications LED
Power
Generic
Auto test button
Service button and LED
Communications LED
Status LED
