the communication jack is wired to the communication link at the controller. By
accessing the communication jack via Rover, you gain access to any controller
on the link.
Zone sensor wiring connections
Table 30 Typical Trane zone sensor wiring connections
TB1 Description
1 Space temperature
2 Common
3 Setpoint
4Fan mode
5 Communications
6 Communications
