Physical specifications
Board dimensions
Height: 5.25 in. (133 mm)
Width: 5.50 in. (140 mm)
Depth: 2.25 in. (57 mm)
Operating environment
32° to 140°F (0° to 60°C)
5% to 95% relative humidity, non-condensing
Storage environment
-40° to 185°F (-40° to 85°C)
5% to 95% relative humidity, non-condensing
Agency listings
UL and CUL 916 Energy Management System
Agency compliance
IEC 1000-4-2 (ESD), IEC 1000-4-4 (EFT), IEC 1000-4-5 (Surge)
Power requirements
18 to 32 VAC (24 VAC nominal)
50 or 60 Hz
570 mA AC
Binary inputs
Table 3 Binary inputs (typically 24 mA AC)
Note: Each binary input associates an input signal of 0 VAC with open contacts and 24 VAC with closed
contacts.
Description Terminals Terminal function
Binary input 1
(BI 1)
J2-1 24 VAC
J2-2 Input
Binary input 2
(BI 2)
J2-3 24 VAC
J2-4 Input
Binary input 3
(BI 3)
J2-5 24 VAC
J2-6 Input
Binary input 4
(BI 4)
J2-7 24 VAC
J2-8 Input
