Trane Tracer ZN.520

CNT-SVX04A-EN
Troubleshooting
90
Table 58 Test sequence for non-face and bypass unit configurations
Note
1
: Upon entering manual output test mode, the controller turns off all fan and electric heat outputs
and drives all dampers and valves closed (if required).
Note
2
: At the beginning of step 2, the controller attempts to clear all diagnostics.
Note
3
: If the unit is configured for a 3-speed fan, the medium fan speed output will energize at step 3.
If the unit is configured for a 2-speed fan, the fan remains on high speed at step 3.
Note
4
: If the unit is configured for a 3-speed fan, the medium fan speed output energizes at step 3. If
the unit is configured for a 2-speed fan, the low fan speed output engergizes at step 3. If the unit is
configured for a 1-speed fan, the fan remains on high speed at step 3.
Note
5
: If the unit is configured for a 1- or 2-speed fan, the exhaust fan output energizes on step 7. The
exhaust fan output is shared with medium fan speed.
Note
6
: After step 10, the test sequence performs an exit. This initiates a reset and attempts to return
the controller to normal operation.
Step Fan
DX, or cool or
heat/cool
changeover
valve
Face/ bypass
damper
Electric heat, or
heat valve
Outdoor air
damper
Generic/
baseboard
heat
J1-1 J1-2 J1-3 J1-5 J1-6 J1-7 J1-8 J1-9 J1-10 J1-11 J1-12 TB4-1
1: Off
1
Off Off Off Off On NA NA Off Hydronic: on
EH: off
Off On Off
2: Fan high
2
High Off Off Off Off NA NA Off Off Off Off Off
3: Fan med
3
Off Med Off Off Off NA NA Off Off Off Off Off
4: Fan low
4
Off Off Low Off Off NA NA Off Off Off Off Off
5: Main open, DX
on
High Off Off On Off NA NA Off Off Off Off Off
6: Main close, DX
off, aux open, EH1
on
High Off Off Off On NA NA On Off Off Off Off
7: Aux open, EH1
on, exhaust fan
5
High Exh Off Off Off NA NA On Off Off Off Off
8: Aux close, EH1
off, EH2 on,
damper open
High Off Off Off Off NA NA Off On On Off Off
9: Damper close High Off Off Off Off NA NA Off Off Off On Off
10: Generic/
baseboard heat
energized
High Off Off Off Off NA NA Off Off Off Off On
11: Exit
6
