Section 3. Installation
3.1 Contents and Specifications
The following parts are included in product
model TZONE940AC52Z:
1 - Communicating Sensor
1 - Base
2 - Mounting screws/anchors
1 - Installation/User’s Guide
Specification Description
Product Model: ZONE940AC52Z
Product: ComfortLink II™ Communicating Sensor
Size: 5.5” width x 3.4” height x 1.1” depth
Storage Temperature: -40°F to 170°F, 0% - 95% RH
Operating Temperature: 32°F - 120°F, 5% - 90% RH non-condensing
Power:
24 VAC from HVAC System (Range: 18-32 VAC)
Power Consumption: 2 VA
Wire usage: Minimum 18 gauge NEC approved control wiring
Scan to see a
video on installing
and setting up the
940 Zone Sensor.
