19
940 Sensor Setup Table
Data
Setup
Number
Setting
Range
Default
Setting
ONLY for Installers Zone Address 1 1-8 1
User Settings
Active Brightness 2 0-10 10
Standby Brightness 3 0-10 0
Backlight Timeout 4 5-60 (sec) 10
Clean Screen Timeout 5 5-60 (sec) 30
3.7 Optional User Display Settings
The setup screen allows changing of display settings. These features can be adjusted by changing the
SETUP NUMBER and changing the SETTING range in the same manner as the Zone Address was set
in the previous section. Please see the matrix below.
NOTE: To enter this setup screen, press and hold INDOOR TEMPERATURE for approximately 5
seconds.
