Trane UniTrane Fan-Coil Installation Operation & Maintenance

Dimensions
and Weights
UNT-PRC001-EN 43
Vertical
Concealed
Vertical Concealed Unit Dimensions
Unit
Size 02-03 04 06 08 10-12
A2’-8
11
/16” 3’-1
11
/16” 3’-11
3
/16” 4’-7
11
/16” 6’-2
11
/16”
B1’-9
5
/16” 2’-2
5
/16” 2’-11
13
/16” 3’-8
5
/16” 5’-3
5
/16”
C1’-10
13
/16” 2’-3
13
/16” 3’-1
5
/16” 3’-9
13
/16” 5’-4
13
/16”
D1’-5
5
/16” 1’-10
5
/16” 2’-7
13
/16” 3’-4
5
/16” 4’-11
5
/16”
E1’-7
5
/16” 2’-0
5
/16” 2’-9
13
/16” 3’-6
5
/16” 5’-1
5
/16”
NOTE:1. Coil connections are always on the drain pan side and opposite
the control box.
2. Coil connections are
5
/8” O.D. sweat. See page 53 for locations.
3. All duct collar dimensions are to the outside of the collar.
4. See page 54 for fresh air opening dimensions.
Vertical Concealed, Model A
