Trane UniTrane Fan-Coil Installation Operation & Maintenance

Dimensions
and Weights
UNT-PRC001-EN44
Vertical Cabinet
Vertical Cabinet Unit Dimensions
Unit
Size 02-03 04 06 08 10-12
A2’-9
5
/16” 3’-2
5
/16” 3’-11
3
/16” 4’-8
5
/16” 6’-3
5
/16”
B1’-9
5
/16” 2’-2
5
/16” 2’-11
3
/16” 3’-8
5
/16” 5’-3
5
/16”
C7
5
/8” 7
1
/8” 8
7
/8” 7
1
/8” 7
5
/8”
D1’-6” 2’-0” 2’-6” 3’-6” 5’-0”
E1’-7
5
/16” 2’-0
5
/16” 2’-9
13
/16” 3’-6
5
/16” 5’-1
5
/16”
F3’-5
5
/16” 3’-10
5
/16” 4’-7
3
/16” 5’-4
5
/16” 6’-11
5
/16”
NOTE:1. Coil connections are always on the drain pan side and opposite the
control box.
2. Coil connections are
5
/8” O.D. sweat. See page 52 for locations.
3. All duct collar dimensions are to the outside of the collar.
4. See page 54 for fresh air opening dimensions.
Vertical Cabinet, Model B
