Dimensions
and Weights
UNT-PRC001-EN 45
Horizontal Concealed Unit Dimensions
Unit
Size 02-03 04 06 08 10-12
A2’-8
11
/16” 3’-1
11
/16” 3’-11
3
/16” 4’-7
11
/16” 6’-2
11
/16”
B1’-9
5
/16” 2’-2
5
/16” 2’-11
13
/16” 3’-8
5
/16” 5’-3
5
/16”
C1’-10
13
/16” 2’-3
13
/16” 3’-1
5
/16” 3’-9
13
/16” 5’-4
13
/16”
D1’-7
3
/8” 2’-0
3
/8” 2’-9
7
/8” 3’-6
3
/8” 5’-1
3
/8”
E1’-6
1
/8” 1’-11
1
/8” 2’-8
5
/8” 3’-5
1
/8” 5’-0
1
/8”
F1’-7
5
/16” 2’-0
5
/16” 2’-9
13
/16” 3’-6
5
/16” 5’-1
5
/16”
NOTE:1. Coil connections are always on the drain pan side and opposite the
control box.
2. Coil connections are
5
/8” O.D. sweat. See page 52 for locations.
3. All duct collar dimensions are to the outside of the collar.
4. See page 53 for fresh air opening dimensions.
Horizontal
Concealed
Horizontal Concealed, Model C
