Dimensions
and Weights
UNT-PRC001-EN54
Fresh Air Opening Locations
Vertical Units Models A, B, and J
Fresh Air Opening Dimensions, Vertical Units
Unit
Size 02-03 04 06 08 10-12
A1’-6” 1’-11” 2’-8
1
/2” 3’-5” 5’-0”
B1’-9
5
/16” 2’-2
5
/16” 2’-11
13
/16” 3’-8
5
/16” 5’-3
5
/16”
Fresh Air
Opening
VERTICAL
CONCEALED AND RECESSED
VERTICAL
CABINET AND SLOPE TOP
