48 Optional Equipment (for qualified installers only)
© Travis Industries 4140808 100-01298
4. Remove and discard the stock seal plates. Install the LP seal plates as shown below.
5. Install the LP (propane) orifices.
ORIFICE SIZE (ID)
Natural Gas LP (Propane)
Front Burner Orifice #44 DMS #54 DMS
Rear Burner Orifice #45 DMS 1.25mm DMS
Front Orifice
Rear Orifice
Stock Seal Plate
LP Seal Plate
Stock Seal Plate
LP Seal Plate
To Next Page
