10 TREK SERVICE INFORMATION August 2016
3. Loosen and remove the three aerobar attachment bolts (Figure 6.10), and remove the
aerobar/mono-extension assembly.
Note: To simply remove the fork, you can skip this step and leave the mono-extension
assembly attached to the aerobar.
4. Loosen the steering axle pinch bolt (Figure 6.11).
Figure 6.11. Steering axle pinch bolt
Figure 6.13. Stem aachment bolts (two)
5. Loosen and remove the steering axle lock bolt and washer (Figure 6.12).
6. Note: Support the fork after removing the stem; its only attachment will be the lower
bearing.
Loosen and remove the two stem attachment bolts (Figure 6.13), and remove the stem.
Figure 6.12. Steering axle and steering axle lock bolt
Figure 6.10. Aerobar aachment bolts (three)
7. Note: The fork will detach when the steering axle is removed.
While you support the fork, loosen and remove the steering axle.
