31 TREK SERVICE INFORMATION August 2016
9. Install the front (20 mm) brake cover attachment bolt (Figure 11.10). Tighten to 2 Nm.
Figure 11.12. Centering the rear brake with cover
installed, and without.
Figure 11.11. Aaching the rear brake cover with two 10
mm bolts
10. Install the two rear (10 mm) brake cover attachment bolts (Figure 11.11).
Tighten to 3 Nm.
Figure 11.10. Aaching the rear brake cover with front
20 mm bolt
If needed, you can re-center the brake through the window of the cover (Figure 11.12). Both
centering screws are accessible through this window.
