CDJ300 & CDJ600
-12--12-
Setting up the
Router
Isolate router from
power supply.
Fit relevant guide
bush to router. Refer
to table in each
appropriate section.
Fit fine height adjuster
(if available) to router.
(Not required for
dowel jointing.)
Plunge the router so
that the collet nearly
touches guide bush to
minimise protection of
the cutter.
Fit router cutter into
router.
Set cutter height.
Refer to table in
relevant sections.
1
2
3
4
5
6
