TECHNICAL DATA
Material thickness min. 12mm
max. 47mm
Tenon thickness min. 4.8mm
max. 16mm
Using Vertical Guide:
Tenon length max. 90mm
+
Mortise length max. 90mm
++
Angle tilt compound -10° to 45°
Weight 6kg
+
on end of 100mm wide material
++
unlimited if vertical guide is removed and
wood is repositioned
The following symbols are used throughout this
manual:
Denotes risk of personal injury, loss of
life or damage to the tool in case of non-
observance of the instructions in this
manual.
Refer to the instruction manual of
your power tool.
This unit must not be put into service until it has
been established that the power tool to be
connected to this unit is in compliance with
2006/42/EC (identified by the CE marking on the
power tool).
CONTENTS
TECHNICAL DATA _____________________1
SAFETY ____________________________2-3
ITEMS ENCLOSED ____________________4
DESCRIPTION OF PARTS_______________5
ACCESSORIES _______________________ 6
ASSEMBLY & ADJUSTMENT ____________7
– Assembly of the Top Plate ______________8
– Cutter & Guide Bush Selection __________9
– Fitting of Guide Bushes _______________10
– Fitting the Optional Dust Extraction Kit ___11
TIMBER PREPARATION & MARKING OUT
– Marking out the tenon ________________12
OPERATION
– Set Timber Height ___________________13
– Set Tenon Length____________________14
– Set Centre Line _____________________15
– Routing Procedure ___________________16
– Side Angled Tenon___________________17
– Front Angled Tenon __________________18
– Setting Up for the Mortise _____________19
– Cutting the Mortise___________________20
– Square Mortise & Tenons______________21
– Dowelling _______________________22-23
MAINTENANCE ______________________23
ENVIROMENTAL PROTECTION &
GUARANTEE ________________________23
SPARE PARTS
– Spare Parts List _____________________24
– Spare Parts Diagram _________________25
Max 1-7/8"
(47mm)
Up to 4" (100mm) unlimited
if wood is repositioned
Max 3-1/2” (90mm) tenon length
using vertical guide
5/8"
(16mm)
3/16" (4.75mm)
Min
1/2"
(12mm)
Min/Max Mortise & Tenon Sizes
