MT/JIG
-24-
MT/JIG - SPARE PARTS LIST v2.0 01/2004
No. Qty. Desc. Ref.
1 4 F Clamp for MT/JIG WP-MT/01
2 1 MT/JIG Set-up Bar UK WP-MT/02/UK
1 MT/JIG Set-up Bar EURO WP-MT/02/EURO
3 1 Label Trend MT/JIG WP-MT/03
4 1 Main Body WP-MT/04
5 1 Vertical Guide WP-MT/05
6 1 Inner Body WP-MT/06
7 1 Tilting Back Plate WP-MT/07
8 1 Top Plate WP-MT/08
9 1 Back Clamp Plate Packing Piece WP-MT/09
10 3 Pivot Bush WP-MT/10
11 1 F Clamp Square Cap WP-MT/11
12 1 Back Clamp Plate WP-MT/12
13 1 Front Clamp Plate Packing Piece WP-MT/13
14 1 Front Clamp Plate WP-MT/14
15 1 Template Long WP-MT/15
16 1 Template Short WP-MT/16
17 2 Adjustable Lever M6 x 15mm CR/KB/PK8
18 3 Machine Screw Button M6 x 16mm Skt WP-SCW/75
19 2 Adjustable Lever M6 Female CR/KB/PK9
20 2 Nut Hex M6 WP-NUT/06
21 2 Washer M6 Form C WP-WASH/12
22 6 Machine Screw Button M6 x 12mm Skt WP-SCW/73
23 1 Guide Bush Set Plastic Imperial 6 off UK WP-MT/23/UK
1 Guide Bush Set Plastic Metric 6 off EURO WP-MT/23/EURO
24 1 Guide Bush 25.4mm (1”) Diameter UK GB254
1 Guide Bush 30mm Diameter EURO GB30
25 1 Guide Bush Collar 25.4mm to 54mm UK GB/COLL/25454
1 Guide Bush Collar 30mm to 54mm EURO GB/COLL/3054
26 1 T Handle Hex Key 4mm x 150mm HK/T/04
27 4 Self Tapping Screw Pan No.10 x
3
⁄
4
Pozi WP-SCW/108
28 2 Clamping Bar Shims WP-MT/28
29 1 Manual MANU/MT
DUST EXTRACTION KIT (OPTIONAL)
30 1 Dust Kit Complete MT/DUSTKIT
31 1 Dust Shield WP-MT/31
32 1 Dust Spout WP-SRT/16
33 1 Magnet Pack 10mm x 3mm (Pack of 4) MAG/PACK/2
34 4 Machine Screw Button Flange M6 x 12mm Skt WP-SCW/73
35 4 M6 Internal Shakeproof Washer WP-WASH/31
36 4 Nut Hex M6 WP-NUT/06
37 0 Hose Adaptor 58mm to 39mm CRT/3
38 1 Adaptor Body for CRT/3 WP-CRT/97
39 1 Adaptor Fitting for CRT/3 WP-CRT/98
40 1 Adaptor Clip for CRT/3 WP-CRT/99
CUTTER SETS (OPTIONAL)
41 0 Cutter Set Imperial 5pc UK SET/MT1
0 Cutter Set Metric 5pc EURO SET/MT2
