T10 & T11
-23-
T10 & T11- SPARE PARTS LIST v1.0 03/2005
No. Qty. Desc. Ref.
1 1 Armature 115V T10EL & T11EL WP-T10EL/001
1 Armature 230V T10E & T11E WP-T10E/001
2 1 Field Coil 115V T10EL & T11EL WP-T10EL/002
1 Field Coil 230V T10E & T11 WP-T10E/002
3 1 Switch WP-T10/003
4 2 Carbon Brush 115V (1 pair) WP-T10EL/004
2 Carbon Brush 240V (1 pair) WP-T10E/004
5 1 2 Core Cable Only 115V UK T10L & T11L WP-T10L/005
1 2 Core Cable with Plug 230V UK T10 & T11 WP-T10/005
1 2 Core Cable with Plug 230V Euro T10/T11EURO WP-T10EUR/005
6 2 Brush Holder WP-T10/006
7 1 Top Vent Housing WP-T10/007
8 1 Field Housing WP-T10/008
9 2 Lead Yellow 115V T10L & T11L WP-T10L/009
2 Brush Lead 230V T10 & T11 WP-T10/009
10 1 Lead (Red x 105mm) WP-T10/010
11 1 Switch Lever WP-T10/011
12 1 Machine Screw Csk M4 x 6mm Phillips WP-T10/012
13 1 Switch Slider WP-T10/013
14 2 Brush Holder Clamp WP-T10/014
15 4 Screw Self Tapping Pan 3.8mm x 12mm Phillips WP-T10/015
16 1 Top Bearing 12mm x 32mm x 10mm 6201-2RSL WP-T10/016
17 1 Circlip WP-T10/017
18 2 Screw Self Tapping Dome 4mm x 25mm Phillips WP-T10/018
19 1 Cable Guard 115V T10L & T11L WP-T10L/019
1 Cable Guard 240V T10 & T11 WP-T10/019
20 4 Bolt Pan M5 x 68mm Phillips WP-T10/020
21 4 Washer Split M5 WP-T10/021
22 2 Screw Self Tapping Pan 3.2mm x 13mm Phillips WP-T10/022
23 1 Cable Clamp WP-T10/023
24 1 Lead Switch to Speed Control (Red x 95mm) WP-T10/024
25 - - -
26 1 Depth Stop Support (Left Hand) WP-T10/026
27 1 Depth Stop Support (Right Hand) WP-T10/027
28 1 Depth Stop Lens WP-T10/028
29 4 Screw Self Tapping Dome 3.8mm x 14mm PH WP-T10/029
30 1 Half Nut Hex M12 WP-T10/030
31 2 Screw Self Tapping Dome 4.8mm x 63mm PH WP-T10/031
32 1 Fan Baffle WP-T10/032
33 1 Fan WP-T10/033
34 1 Washer WP-T10/034
35 1 Plunge Lock Lever WP-T10/035
