T10 & T11
-1-
Dear Customer
Thank you for purchasing this Trend product, we
hope you enjoy many years of creative and
productive use.
Please remember to return your guarantee card
within 28 days of purchase.
CONTENTS
TECHNICAL DATA _____________________1
SAFETY ____________________________2-3
ELECTRICAL SAFETY _________________4
MANUFACTURERS DECLARATION ______5
ITEMS ENCLOSED ____________________5
DESCRIPTION OF PARTS _____________6-7
ASSEMBLY & ADJUSTMENT
– Switching On & Off____________________8
– Depth of Cut_________________________8
– Fitting & Removing Cutters _____________9
– Speed Control ______________________10
– Fixing Points for Accessories ___________10
T10
– Dust Extraction Spout ________________11
– Fine Height Adjuster Accessory _________11
T10 & T11
– Template Guide Bush_________________12
T11
– Dust Extraction Spout ________________13
– Fine Height Adjuster__________________14
– Accessories ________________________15
OPERATION
– Cutting Direction & Feed Speed ________16
– Side-fence Routing___________________17
– Template Guide Bush Routing __________18
– Beam Trammel Routing Accessory ______19
– Bearing Guided Cutters _______________20
– Freehand Routing & Batten Routing _____21
MAINTENANCE & CARE_______________22
RECYCLING _________________________22
GUARANTEE ________________________22
SPARE PARTS
– Spare Parts List __________________23-26
– Spare Parts Diagram _________________27
TECHNICAL DATA
Voltage: UK & Eire 230V
UK & Eire 115V
Europe 230V
Power input 2000W
Power output 1400W
No load speed (min.) 8,000-20,000 rpm
Router carriage 2 columns
Router carriage stroke 80mm
Revolver depth stop 3-step, turret stop
adjustment with
graduation
Collet size: UK & Eire
1
/2 inch (12.7mm)
Europe 12mm
Cutter diameter, max. T10 50mm
T11 75mm
Weight 5.2kg
Fuse: UK & Eire 230V 13A in plug
UK & Eire 110V 32A in mains
Europe 230V 10A in mains
The following symbols are used throughout this
manual:
Denotes risk of personal injury, loss of life
or damage to the tool in case of non-
observance of the instructions in this
manual.
Denotes risk of electric shock.
For 115 Volt
The 115V router is not supplied with a plug.
We recommend a 32A BS4343 110V plug is
used. Minimum generator or transformer
requirement 3000 kVA continuous with a 32A
BS4343 110V socket outlet.
The 115V router cannot be used with a 115V
No-Volt Release Switch.
INTENDED USE
The router is intended for routing grooves, edges,
profiles and slots as well as copy routing in wood,
wood based products and plastic. At reduced
speed with the appropriate router cutter fitted
non-ferrous alloys can also be routed.
If you require further technical
information or spare parts, please call
our technical support department on
01923 224681.
