T9
-20-
T9 - SPARE PARTS LIST v4.0 08/2003
No. Qty. Desc. Ref.
1 1 Stator Housing WP-T9/001
2 1 Top Vent Housing WP-T9E/002
3 1 Plunge Depth Stop Knob WP-T9/003
4 1 Speed Control Circuit Board 230V (T9E &
T9/EURO) WP-T9E/004
1 Speed Control Circuit Board 110V (T9EL) WP-T9EL/004
5 1 Cable Guard WP-T9/005
6 1 2 Core Cable With Plug 230V UK (T9) WP-T9/006
1 2 Core Cable With Plug 110V UK (T9L) WP-T9L/006
1 2 Core Cable With Plug 230V Euro (T9/EURO) WP-T9EURO/006
7 1 Carbon Brush 230V (1 pair) WP-T9E/007
1 Carbon Brush 110V (1 pair) WP-T9EL/007
8 2 Brush Holder 230V WP-T9/008
2 Brush Holder 110V WP-T9L/008
9 2 Brush Spring Clip WP-T9/009
10 1 Cable Clip WP-T9/010
11 1 Graduated Ring WP-T9/011
12 1 Depth Stop Adjustment knob WP-T9/012
13 4 Screw Self Tapping 3.9mm x 22mm Pozi WP-T9/013
14 1 Field Coil Complete 230V (T9E & T9/EURO) WP-T9E/014
1 Field Coil Complete 110V (T9EL) WP-T9EL/014
15 2 Machine Screw Pan M5 x 90mm Pozi WP-T9/015
16 1 Deflector WP-T9/016
17 1 Magnet For Speed Control WP-T9E/017
18 1 Magnet Holder Cover WP-T9E/018
19 1 Bearing Cover WP-T9/019
20 1 Top Bearing 9mm x 26mm x 8mm 629ZZ WP-T9/020
21 1 Armature 230V (T9E & T9/EURO) WP-T9E/021
1 Armature 110V (T9EL) WP-T9EL/021
22 1 Fan For Armature WP-T9/022
23 1 Armature/Bearing Ring WP-T9/023
24 1 Bottom Bearing 25mm x 47mm x 12mm 60005Z WP-T9/024
25 1 Bearing Plate WP-T9/025
26 1 Spindle Lock Body WP-T9/026
27 1 Spindle Lock Spring WP-T9/027
28 1 Spindle Lock Button WP-T9/028
29 1 Spindle Lock Stud WP-T9/029
30 1 Collet 6.35mm (T9 & T9L) CLT/T9/635
1 Collet 12.7mm (T9 &T9L) CLT/T9/127
1 Collet 12mm (T9/EURO) CLT/T9/12
31 1 Collet Nut
CL
T/NUT/T9
32 4 Bush For Columns (s/n 100001-101807) WP-T9/032
