TREND T9 - Page 22

T9
-21-
T9 - SPARE PARTS LIST v
4.0 08/2003
No. Qty. Desc. Ref.
33 1 Cable Conduit Lower WP-T9/033
34 1 Cable Conduit Upper WP-T9/034
35 1 Switch 230V (T9E & T9/EURO) WP-T9E/035
1 Switch 110V (T9EL) WP-T9EL/035
36 1 Handle Inner Right WP-T9/036
37 1 Handle Outer Right WP-T9/037
38 1 Handle Inner Left WP-T9/038
39 1 Handle Outer Left WP-T9/039
40 1 Plunge Locking Lever WP-T9/040
41 1 Plunge Lever Bolt WP-T9/041
42 1 Depth Stop WP-T9/042
43 2 Plunge Spring (s/n 100001-101807) WP-T9/043
43A 2 Plunge Spring (s/n 101808›) WP-T9/043A
44 2 Nut Hex M4 WP-NUT/04
45 6 Thumb Knob Male M6 x 16mm WP-T9/045
46 1 Parallel Side-fence Complete WP-T9/046
47 1 Parallel Side-fence Casting WP-T9/047
48 1 Side-fence Cheeks (Pair) WP-T9/048
49 1 Guide Rods 10mm x 450mm ROD/10X450
50 - - -
50A 1 Base Casting (s/n 101808›) WP-T9/050A
51 1 Micro Fence Adjuster End Stud WP-T9/051
52 1 Micro Fence Adjuster Barrel WP-T9/052
53 1 Micro Fence Adjuster Knob Stud WP-T9/053
54 1 Micro Fence Adjuster Thumb Knob WP-T9/054
55 - - -
56 1 Bearing Ring Circlip WP-T9/056
57 1 Washer 2mm x 10mm x 0.4mm WP-T9/057
58 1 Spacer For Revolving Guide WP-T9/058
59 1 Revolving Guide WP-T9/059
60 1 Ball For Revolving Guide WP-T9/060
61 1 Spring For Revolving Guide WP-T9/061
62 1 Machine Screw Pan Head M5 x 16mm Pozi WP-T9/062
63 3 Nut Hex M5 WP-NUT/05
64 3 Threaded Pin M5 x 16mm WP-T9/064
65 1 Phenolic Base Slider WP-T9/065
66 1 Spanner 22mm A/F SPAN/22
67 1 Lower Bearing Housing (s/n 100001-101807) WP-T9/067
67A 1 Lower Bearing Housing c/w Bushes
(s/n 101808›)
WP-T9/067A
68 1 Magnet Washer WP-T9E/068
69 1 Machine Screw LH M4 x 10mm Slot WP-T9E/069
