T9
-22-
T9 - SPARE PARTS LIST
v4.0 08/2003
No. Qty. Desc. Ref.
70 1 Conduit Cap WP-T9/070
71 2 Cable Block WP-T9/071
72 1 Block Pad WP-T9/072
73 2 Foam Packing WP-T9/073
74 1 Handle Anti-slip WP-T9/074
75 1 Inner Plate WP-T9/075
76 2 Machine Screw Pan M5 x 12mm Slot WP-SCW/42
77 2 Machine Screw Csk M5 x 8mm Slot WP-SCW/09
78 6 Spring For Thumb Knob WP-T9/078
79 1 Grub Screw M5 x 18mm WP-T9/079
80 4 Machine Screw Pan M5 x 10mm Pozi WP-SCW/44
81 5 Washer 5.4mm x 9.7mm x 1mm WP-T9/081
82 2 Grub Screw M5 x 14mm (s/n 100001-101807) WP-T9/082
83 6 Machine Screw Csk M4 x 8mm Pozi WP-SCW/54
84 2 Machine Screw Pan M5 x 10mm Pozi WP-SCW/44
85 1 Machine Screw Pan M5 x 14mm Pozi WP-SCW/45
86 6 Screw Self Tapping 4.8mm x 19mm Pozi WP-T9/086
87 2 Machine Screw Pan M4 x 14mm Pozi WP-SCW/46
88 3 Screw Self Tapping 4.8mm x 45mm Pozi WP-T9/088
89 2 Machine Screw Socket M8 x 20mm WP-SCW/47
90 1 Line Up Pin 12mm &
1
/
2
” Shank WP-T9/090
91 - - -
92 1 Fibre Washer WP-T9/092
93 2 Lead Cable Block to Switch (Blue x 390mm) WP-T9/093
94 2 Lead Switch to Cable Block (Brown x 330mm) WP-T9/094
95 1 Armature Ring WP-T9/095
96 1 Dust Spout WP-T9/096
97 1 Dust Spout Adaptor WP-T9/097
98 1 Dust Spout Insert WP-T9/098
99 2 Lead Brush Holder to Field (Red x 115mm) WP-T9/099
100 1 Screw Self Tapping 4.8mm x 37mm Pozi WP-T9/100
101 2 Machine Screw Pan M5 x 12mm Slot WP-SCW/42
102 2 Washer Split Spring M5 WP-WASH/29
103 0 Base Casting c/w Lower Housing Kit
(s/n 101807›) WP-T9/103
104 1 Plunge Height Adjustment Tube WP-T9/104
105 1 Cable Block and Lead Set 110V (T9EL) WP-T9L/105
106 1 Guide Bush 30mm Diameterl
GB30/A
107 1 Fine height adjuster FHA/002
106 1 Manual MANU/T9
