Pre-Installation Instructions
The pre-installation checklist and site planning must be performed before installing the
equipment at the site.
Site Planning
1. Determine the number and types of meter points required by;
# of elements - single-phase, two-phase, or three-phase.
# of different voltage references
CT types – 80mA, 100mA and/or 333mV
2. Determine the number of pulse inputs required
3. Determine the number of Triacta GATEWAY systems to be installed and ensure adequate
space. For clearances, see Figure 7.
3. Determine the number and types of Measurement Modules required for each Triacta
GATEWAY system.
4. Determine the number of control and/or sense voltage connections required and ensure
that an approved 15-Amp fused disconnect or breaker is provided for each connection.
5. Determine the number of Ethernet drops required, and ensure they are installed before
installing the Triacta GATEWAY system.
Access to Power and Lighting
The installation site must be supplied with access to the main electrical panel and any sub-
panels. Portable or permanent lighting must be available to provide the installers with a clear
view of the equipment and of the installation environment. Each installation may vary
depending on physical site restrictions.
