External Wiring
Locate the system temperature sensor
where it can accurately measure the sup-
ply temperature to the heating system.
Inaccurate system temperature readings
could lead to overheating or under heat-
ing resulting in property damage.
1. Connect the system temperature sensor to
the low voltage terminal strip on the wiring
panel below the PRESTIGE control mod-
ule, as shown in Fig. 19 on page 31.
Cascade Wiring
The TriMax control includes the ability to
operate up to six boilers together as one with-
out the need for external controllers. Consult
the PRESTIGE TriMax Control Supplement
for more information.
Modbus Wiring
The TriMax control includes the ability to
communicate with building management sys-
tems (BMS) through a Modbus interface.
Consult the PRESTIGE TriMax Control
Supplement for more information.
CAUTION
