Triax TDX User Manual

Headend Installation
10
Multi headend installation
Up to three headends can be combined to further increase the number of
services provided.
The headends are physically installed as per installation of single
headend, i.e. by using the supplied brackets described above.
Ventilation
requirements
Ensure that the following ventilation requirements are met:
Horizontal
installation
 Min. 20cm ventilation space must be available between headends.
 Min. 10cm ventilation space must be available outside the end
headends.
 Min. 10cm ventilation space must be available from the front of
each headend.
Vertical installation
 10cm ventilation space must be available on both sides of each
headend.
 10cm ventilation space must be available from the front of each
headend.
