Triax TDX User Manual

IP Output Configurations
54
IP Output configurations
Creating
The headend system offers the following possibilities when you output
IPTV services through the Link sockets.
 IP multicast streaming (UDP streaming)
 No RTP option
 IGMP version 2
 SPTS or MPTS including SDT, PAT, PMT, CAT
 Packet ratio of 1 TS packet per IP packet
 Not possible to change service ID (SID)
Note:
Licenses for IP output are required to be able to use the IPTV
functionality in the headend. The licenses can be purchased from Triax
Sales, and need to be activated, see “Activating licenses”.
1. Select the Output tab.
2. Select the IP outputs sub-tab.
3. Press the Setup button for the link socket that will process IP
output.

Triax TDX Specifications

General

Brand	Triax
Model	TDX
Category	Control Unit
Language	English
