TriBox3 // Use
For better orientation, the following illustration describes the external dimensions in mm and the dimensions of
the mounting holes.
bottom view
bottom
1
1
2
2
3
3
4
4
5
5
6
6
A A
B B
C C
D D
Name: TriBox3
Date: 22.09.2014 Rev.: TD011403
Note: Dimensions in mm
2014- 11- 12
TriOS Mess- und Datentechnik GmbH
● Bgm.- Brötje- Str. 25 ● 26180 Rastede ● Germany
fon: +49 4402 / 69 67 0 - 0
● fax: - 20 ● web: http://www.trios.de ● e- mail: info@trios.de
Dimension Drawing: Assembly instruction of TriBox3
free space for installation
93
~
120 mounting holes
262 mounting holes
280
170
100 MIN
40
~
D
i
s
p
l
a
y
7
'
'
/
1
7
,
8
c
m
recommended
mounting screw
DIN EN ISO 4762
M5x25 or longer
(4 pcs)
TriOS o󰀨ers suitable panels for mounting the TriBox3 (Art.Nr. 11A100000).
