TriBox3 // Malfunction & Maintenance
7 Technical Data
7.1 Technical Specications
POWER SUPPLY
Voltage supply 100...240 VAC, 50...60 Hz, 12...24 VDC (± 5%)
Power consumption Type: 6 W, max: 50 W
Protection class 1
Overvoltage category II
SENSOR INTERFACES
Connection 4 M12 industrial connectors for TriOS sensors
Standard RS-232, RS-485
Protocol Modbus-RTU, TriOS
MODBUS RTU
Server RTU yes (on each sensor connector)
Client RTU yes (on each sensor connector)
Parameters Adjustable (default: 9600-8-N-1)
MODBUS TCP
Server TCP yes
TCP port Adjustable (default: 502)
NETWORK/USB
Standard Ethernet, WiFi based on IEEE 802.11b/g/n
Connection 1 RJ-45 integrated WiFi antenna (for TriBox3 with WiFi)
Protocol TCP/IP, Modbus TCP, VNC
Web interface no
USB USB 2.0 (Host), USB-A socket
ANALOG INTERFACES
Analog Output 6 analogue outputs, congurable: 4...20 mA
Load max. 500 Ω
Connection terminals 1.5 mm² 16 AWG
Error indicator 0 mA
SWITCH INPUT/OUTPUT
Measurement trigger
Trigger for global measurement (galvanically isolated),
Control voltage: 12...24 VDC (± 5%)
Connection terminal: 1.5 mm² (AWG
16)
Control voltage: 12...24 VDC (± 5%)
Connection terminal: AWG 16
Control voltage no
