Triton AMORE User Manual

22
USER OPERATING INSTRUCTIONS
10
SECTIONSECTION
OPERATING FUNCTIONS
Power ‘on’ indicator ring (g.21)
• When the electricity supply to the shower is
switched on at the isolating switch, TRITON
will show on the screen for a few seconds and
the Start/Stop icon will illuminate.
Low pressure indication (g.22)
If the water pressure has fallen below the
minimum required for correct operation of the
shower, the following will happen:
• All heating elements will be switched off,
preventing any undue temperature rises.
• The screen will flash LOW PRESSURE.
• When there is adequate water pressure,
the shower will automatically return to the
original settings selected. The screen will
revert to the water temperature again.
Phased shutdown (g.23)
• When the Start/Stop button is pressed
to end showering, all heating elements are
switched off, but water will continue to flow
for a few seconds, flushing out any remaining
hot water.
The screen will flash Bye while the phased
shutdown operation is in progress and will
turn itself off when the operation is complete.
Phased shutdown makes sure the next user
will not receive a slug of hot water if standing
under the showerhead when the shower is
started.
Safety cut-out
• The unit is fitted with an over-temperature
safety device. In the event of abnormal
operation which could cause unsafe
temperatures within the shower, the device
will disconnect all the heating elements.
Out of temperature range
• If the display shows the words Lo or Hi at
any time, it means that the shower is outside
recommended showering temperatures.
Wait until the screen shows the appropriate
temperature before continuing to shower.
Fig.21
Fig.22
Fig.22
Fig.23

Triton AMORE Specifications

General

Type	Electric Shower
Start/Stop Button	Yes
Phased Shutdown	Yes
Warranty	2 years
Cable Entry Points	Bottom
Material	Plastic
Finish	White
