Triton Omnicare User Manual

11
Outline of shower tray
Cold
water supply
(either top, bottom
or back entry)
Shower unit
can be mounted
either side
of riser rail
Height of
shower
should
be a
minimum
of 1 metre
from base
Spillover level
Height of
shower head
and shower
to suit user's
requirement
Fig.1 Diagrammatic view (not to scale)
For illustration purposes only. Kits may vary.
WARNING
The shower MUST NOT be positioned where
it will be subjected to freezing conditions.
INSTALLATION REQUIREMENTS

Triton Omnicare Specifications

General

Type	Electric Shower
Temperature Control	Thermostatic
Water Connection	15mm compression
Start/Stop Button	Yes
Material	Plastic
Finish	White
Installation Type	Wall Mounted
Warranty	2 years
Water Entry Points	Bottom
Cable Entry Points	Bottom Entry
Approvals	WRAS
