24
INSTALLATION
12
StepStep
Connect the 6-way
cable from the Unit to the
cover PCB. Note: The cable
connector can be fitted to the
socket only one way.
13
StepStep
Guide the cover into position so that the temperature selector locates correctly
onto the valve (minor adjustment of the temperature dial may be necessary to align
with the valve). Apply slight pressure to the cover and secure in position with the 3
retaining screws.

Table of Contents

Other manuals for Triton Omnicare

Preview: Installation And Operating Instructions
Installation And Operating Instructions36 pages

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Triton Omnicare and is the answer not in the manual?

Triton Omnicare Specifications

General IconGeneral
TypeElectric Shower
Temperature ControlThermostatic
Water Connection15mm compression
Start/Stop ButtonYes
MaterialPlastic
FinishWhite
Installation TypeWall Mounted
Warranty2 years
Water Entry PointsBottom
Cable Entry PointsBottom Entry
ApprovalsWRAS
