Fig.33
Fig.35
Fig.34
Fig.32
Maxi
Ultra
Needle
Jet
ADJUSTING THE SPRAYHEAD
(Tyne)
Four sprayhead patterns are available (fig.32).
Adjustment is by turning the bezel on the
sprayhead in either direction until the desired
pattern is obtained.
MAXI: A full spray perfect for a relaxing shower.
ULTRA: A focused spray for a refreshing,
satisfying shower.
NEEDLE: A tingling, fine spray for a highly
invigorating shower.
JET: A concentrated spray for an exhilarating
shower.
CLEANING
Do not use abrasive or solvent cleaning
fluids. The shower unit, riser rail, hose,
etc. should be cleaned using a soft cloth
and warm water.
IT IS IMPORTANT TO KEEP THE SPRAYHEAD
CLEAN TO MAINTAIN THE PERFORMANCE OF
THE SHOWER. The hardness of the water will
determine the frequency of cleaning. For
example, if the shower is used every day in a
very hard water area, it may be necessary to
clean the sprayhead on a weekly basis.
Sprayplate removal
There is no need to remove the sprayhead from
the hose.
Using the removal tool supplied
(fig.33),
locate the three raised ’bosses’ into the three
recesses in the sprayplate. Hold in firmly and
twist anti-clockwise (fig.34). This movement
may turn the cartridge assembly as well until it
reaches a ‘stop’.
Hold the cartridge firmly and continue to twist
anti-clockwise. Having loosened the sprayplate
sufficiently, it can be unscrewed and removed
completely (fig.35).
Clean the sprayplate with a suitable brush or
preferably leave it to soak overnight in a mild
proprietary descalent. Ensure all traces of scale
are removed and thoroughly rinse in clean
water afterwards.
Refit the sprayplate by screwing clockwise. Use
the tool to screw the sprayplate tight.
