Triumph Thunderbird Commander - Indicator Lights; Bulb Replacement

110
Maintenance and Adjustment
Indicator Lights
Bulb Replacement
1. Screwdriver
Use a flat bladed screwdriver to carefully
remove the lens from the indicator to gain
access to the bulb for replacement.
To remove the bulb, gently press inwards and
twist anti-clockwise.
1. Lens
2. Locating tang
3. Bulb
Installation of the bulb is the reverse of the
removal procedure, noting the following:
To install the indicator lens, align the locating
tang with the indicator body and push the
lens until the retaining clips secure the lens.
1
cfhh
Caution
When installing the lens, ensure that the
locating tang is correctly aligned to the
indicator body.
1
2
3
cfhi
