44
General Information
Panniers (if fitted)
To Remove the Panniers
Note:
• The same procedure can be
followed to remove and mount the
left or right hand pannier.
To remove the pannier from the motorcycle,
open the lid of the pannier and remove the
two fixings and their washer. Keep the fixings
and washers with the pannier.
1. Fixings
2. Washers
Pull the top of the pannier away from its
mounting studs.
Lift up the front of the pannier to disengage it
from the front mounting.
Slide the pannier forwards to disengage from
the rear mounting and remove the pannier.
1. Rear mounting
2. Flanged sleeve
3. Rear mudguard
4. Front mounting
